Image Access WideTEK WT48-600

Complete redesign of electronics and improved hardware adds new functionality and enhances
the already acclaimed camera technology

The WideTEK® 48 wide format CCD scanner scans documents up to 48 inches wide (1220 mm). The new mainboard is an Intel® Core Gen 9 processor which ensures faster data processing. Together with a faster 250GB SSD drive, internal processes and the system start time are significantly accelerated.

WideTEK® 48 - Wide Format CCD Scanner for documents up to 48 inch widths

Complete redesign of electronics and improved hardware adds new functionality and enhances
the already acclaimed camera technology

The WideTEK® 48 wide format CCD scanner scans documents up to 48 inches wide (1220 mm). The new mainboard is an Intel® Core? Gen 9 processor which ensures faster data processing. Together with a faster 250GB SSD drive, internal processes and the system start time are significantly accelerated.



The new 7 inch multi-touch display with higher resolution increases the ease of use and improves workflow. And, the configurable dark mode enables the user to work ergonomically and in a way that is easy on the eyes.



Of course, all WideTEK® CCD scanners are delivered with the latest version of the Scan2Net® software.





Upgraded WideTEK 48 Features:





  • Intel® Core™ Gen 9 processor
  • Lightning fast image processing
  • Fast 250GB SSD
  • Powerful, silent micro stepping motors & controls
  • High resolution 7" multi-touch display
  • Improved ON/OFF switch
  • New firmware includes dark mode

Gentle Scanning of Historical and Fragile Documents

WideTEK® 48 wide format scanner gently scans due to special transport rollers that serve as pressure points ensuring safe document transport. For historical and fragile documents, this is critical.

The new background drum does not touch the glass plate at any time, avoiding scratches and document skews. For extra contrast on sepias and film based documents, the standard black background drum can be easily exchanged with a white drum, with no tools required.

Automatic document size recognition means that operators are flexible when feeding a source document into the sheetfeed scanner. It is not necessary to exactly center the document on the scan area. With crop and deskew, the resulting image output will be straight, centered and without black borders.

State of the art illumination using bright white LEDs guarantees long lifetime and a low cost of ownership, since there are practically no consumables necessary over the life of the product. Cutting edge camera technology, with a dust-protected, fully sealed camera box holding CCD systems that use a patented stitching procedure, delivers a scanner resolution of up to 1200 dpi optical.

The user operates the wide format scanner either with a standard internet browser or alternatively, via the built-in touchscreen. A monitor directly connected to the wide format scanner can be used for image control or to modify the scan parameters, without a client PC. Using the touchscreen display, up to 30 different password protected jobs can be defined and stored. The jobs contain preconfigured settings such as scan parameters or directories on the network drives.

Easy to use walk up scanning or mobile scanning with Scan2PAD®

Scan2Pad® lets you control the WideTEK® 48 wide format scanner using an iPad or an Android tablet or even a smartphone running Android version 4.0.3 or higher. For full information on Scan2Pad®click here.

The exceptionally high scanning speed, dust-protected and encapsulated optical components and the absence of consumables characterize this highly efficient production-ready device. With a life expectancy of over one million scans, the WideTEK® 48 redefines the price/performance ratio in the wide format scanner market.

Functions, features and options available on the WideTEK® 48 wide format CCD scanner.

WideTEK® 48 Wide Format CCD Scanner - Functions

  • Scans 48 inch widths
  • Fastest color scanning at 15 inches per second (22.9 m/min) @ 150 dpi
  • 1200 x 1200 dpi scanner resolution
  • Automatic crop & deskew
  • Automatic format- and position recognition of source document anywhere on the scanning bed
  • Virtual rescan, modify images without rescanning
  • Configurable scan templates and target templates
  • Face up scanning (no more "blind"scanning)
  • Real time display of scanned images
  • Wide color gamut, supports Adobe RGB, sRGB and native RGB
  • Standalone device with its own Linux PC
  • Direct output to the integrated USB-Port
  • Scan2Net -- Output to SMB, FTP, Printer, eMail
  • Output formats: Multipage PDF (PDF/A) & TIFF, JPEG, JPEG 2000, PNM, PNG, BMP,
    TIFF (Raw, G3, G4, LZW, JPEG) and many more
  • Complies to FADGI *** guidelines, ISO 19264-1

WideTEK® 48 Wide Format CCD Scanner - Features

  • LED lamps, no warm up, IR/UV free
  • Large color 22 inch touchscreen for direct operation without external PC
  • ScanWizard -- integrated scan application for use with any browser: IE, Edge, Safari, Chrome, Firefox
  • Multilanguage support, customizable user interface
  • Closed loop calibration software
  • Durable, antistatic, all metal paper path
  • Virus resistant Linux OS
  • OS independent, runs with Windows 8, 10, Linux, Mac
  • Gigabit Ethernet Interface
  • Integrated walk up scanning software
  • Easy installation via Scan2Net® Technology
  • Remote maintenance and troubleshooting
  • Firmware updates via web interface

WideTEK® 48 Wide Format CCD Scanner - Options

  • Transparent document carriers for fragile document handling, available in two sizes: A0 and A1
  • Batch Scan Wizard -- Software option for high volume scanning
  • TWAIN Interface -- Software interface option
  • Scan2OCR -- Background text recognition already during the scan job
  • PrintWizard -- Option for direct communication with
    Canon TDS (ColorWave, PlotWave) and iPF, HP PageWide and DesignJet, Epson SureColor
  • Scan2ICC -- Subscription for ICC color management and profiles
  • Scan2Pad® -- Operation via tablet, smartphone or other mobile device
  • Extended resolution -- Extend the resolution to 9600 dpi
  • Full Coverage Warranty -- Up to 5 years subscription for full coverage warranty package and free spare parts



Specifications

Document
Maximum Document Size 1270 mm (50 inch) width. Information about the maximum scan length in the technical specification.
Maximum Scan Width max. 1220 mm (48 inch)
Document Thickness max. 3.0 mm (0.1 inch)
Autoformat Size Recognition yes
DIN Format DIN A5 – DIN A0
ANSI Format Legal, US E
User Defined Format yes
Output
Scanner Resolution 1200 x 1200 dpi (optionally 9600 x 9600 dpi interpolated)
Optical Resolution 1200 x 600 dpi
Pixel Dimension 9.3 x 9.3 µm
Paper Path Face up, Front entry, Front or rear exit
Scan Speed Color 200 dpi – 17 m/min (11.2 inch/s)
300 dpi – 11.4 m/min (7.5 inch/s)
600 dpi – 4.6 m/min (3 inch/s)
1200 dpi – 2.3 m/min (1.5 inch/s)
Scan Speed BW Same as 24 bit Color
Color Depth 48 bit color, 16 bit grayscale
Scan Output 24 bit color, 8 bit grayscale, bitonal, enhanced halftone
File Formats Multipage PDF (PDF/A) and TIFF, JPEG, JPEG 2000, PNM, PNG, BMP,
TIFF (Raw, G3, G4, LZW, JPEG), AutoCAD DWF, JBIG, DjVu,
DICOM, PCX, Postscript, EPS, Raw data and more
ICC Profiles Embedded for sRGB, Adobe RGB and native. Individual profiling via web based Scan2ICC subscription.
Quality Complies to FADGI *** guidelines, ISO 19264-1
Accuracy
Scan direction ± 0.08% across 48 inch scanning width
Transport direction ± 0.08%
Technical Specifications
Computer 64 bit Linux, Intel® Core Gen 9 processor,
250GB SSD, 16GB RAM for very long scans
Touchscreen 7 inch multi-touch display
Monitor 22 inch touchscreen with arm (included in the bundle)
USB Port 1 USB 3.0 Port
Interface 1 GBit Fast Ethernet with TCP/IP based Scan2Net® interface
Camera 4x Tri-color CCD camera, 90,000 pixels, encapsulated and dust-proof
Light Source Two linear lamps with white LEDs, no IR/UV emission
Declaration about the Emission of UV and IR radiation
Lamp Lifetime 50,000 hours typ. Lamps are covered by the Extended Warranty Option
Dimensions
Dimensions Scanner
(H x W x D)
228 x 1425 x 507 mm (9 x 56 x 20 inch)
Weight Scanner 60 kg (132 lbs.)
Electrical Specifications
Electrical Connection 100-240 V AC, 47 – 63 Hz (external power supply,
complies with ECO standard CEC level VI)
Power Consumption < 0.5 W (Sleep) / 6.5 W (Standby) /
60 W (Ready to Scan) / < 120 (Scanning)
Ambient Conditions
Operating Temp 5 to 40 °C (40 to 105 °F)
Rel Humidity 20 to 80 % (non-condensing)
Noise < 35 dB(A) (Scanning) / < 25 dB(A) (Standby)
Hardware
Monitor Options WT-TOUCH22
Stand Options WT48-STANDWT48-STAND-ADJ

Technical changes, errors and omissions excepted. All information subject to change.

Options

Install/Training

Docuvan will provide a number of key environmental and IT Setup requirements prior to delivery of your scanner.  This will enable you to place the scanner in a suitable location and connect it to your network once it arrives.
It also means we will be as efficient as possible in getting you up to speed with your new scanner without typical IT delays,
once we come on site or remote connect to it for the setup, configuration and training.

Because the Bookeye has a built-in Linux PC and is managed from a simple interface on a touch screen, it very quick to get up to speed with.

There is also a web interface that can be used for setup and configuration of the scanning profiles from a PC on the same network, if you want to do it that way, using a Poweruser login.
We provide On-Site Training for multiple staff, if required.  This can be broken into Administrator and User Training, if required.

Alternatively, we offer remote training over the internet, using TeamViewer or Microsoft Teams, connected to your scanner, so we can configure the scanner to your needs as part of the training.
This can be more cost effective where travel and accommodation costs are prohibitive.  (Or we are subject to travel restriction such as during covid)

This would require the IT component to be pre-configured so it can be accessed remotely.
